CD4052BPWR

cd4052bpwr, CMOS Analog Multiplexer, -0.5V to 20V, ±10mA, SOP, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.14~0.14 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 4000 :	0.14 / Piece

PartNumber:: CD4052BPWR

Brand:: Texas Instruments - TI | Pack: | D/C: 10+

Availability:: Supply Ability: 4000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-09

From Other Seller

Part Number:CD4052BPWR
US $0.14 - 0.14
Quantity:

piece

Product Summary

The cd4052bpwr is a single 8-Channel multiplexer having three binary control inputs, A, B, and C, and an inhibit input. The three binary signals select 1 of 8 channels to be turned on and connect one of the 8 inputs to the output. The cd4052bpwr is a differential 4-Channel multiplexer having two binary control inputs, A and B, and an inhibit input. The two binary input signals of the cd4052bpwr select 1 of 4 pairs of channels to be turned on and connect the analog inputs to the outputs. The applications are Analog and Digital Multiplexing and Demultiplexing, A/D and D/A Conversion, Signal Gating.

Parametrics

cd4052bpwr absolute maximum ratings: (1) Supply Voltage (V+ to V-) Voltages Referenced to VSS Terminal: -0.5V to 20V; (2) DC Input Voltage Range: -0.5V to VDD +0.5V; (3) DC Input Current, Any One Input: ±10mA.

Features

cd4052bpwr features: (1) Wide Range of Digital and Analog Signal Levels. Digital: 3V to 20V. Analog: 20VP-P; (2)Low ON Resistance, 125Ω (Typ) Over 15VP-P Signal Input Range for VDD-VEE = 18V; (3)High OFF Resistance, Channel Leakage of 100pA (Typ) at VDD-VEE = 18V; (4)Logic-Level Conversion for Digital Addressing Signals of 3V to 20V (VDD-VSS = 3V to 20V) to Switch Analog Signals to 20VP-P (VDD-VEE = 20V); (5)Matched Switch Characteristics, rON = 5Ω (Typ) for VDD-VEE = 15V; (6)Very Low Quiescent Power Dissipation Under All Digital-Control Input and Supply Conditions, 0.2μW (Typ) at VDD-VSS = VDD-VEE = 10V; (7)Binary Address Decoding on Chip; (8)5V, 10V, and 15V Parametric Ratings; (9)100% Tested for Quiescent Current at 20V; (10)Maximum Input Current of 1μA at 18V Over Full Package Temperature Range, 100nA at 18V and 25oC; (11)Break-Before-Make Switching Eliminates Channel Overlap.
