OPA277P

OPA277P, amplifier, 18V, 134dB, 10mV, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.50 / Piece

PartNumber:: OPA277P

Brand:: Burr-Brown Corporation - BB | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-04

From Other Seller

Part Number:OPA277P
US $1.50 - 1.50
Quantity:

piece

Product Summary

The OPA277P is a high precision operational amplifier. The OPA277P precision op amps replace the industry standard OP-177. The OPA277P offers improved noise, wider output voltage swing, and are twice as fast with half the quiescent current. Features include ultra low offset voltage and drift, low bias current, high common-mode rejection, and high power supply rejection. Single, dual, and quad versions have identical specifications for maximum design flexibility. The OPA277P op amp operates from ±2V to ±18V supplies with excellent performance. Unlike most op amps which are specified at only one supply voltage, the OPA277P is specified for real-world applications; a single limit applies over the ±5V to ±15V supply range.

Parametrics

OPA277P absolute maximum ratings: (1)Supply Voltage: 36V; (2)Input Voltage: (V–) –0.7V to (V+) +0.7V; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –55℃ to +125℃; (5)Storage Temperature: –55℃ to +125℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃.

Features

OPA277P features: (1)Ultra low offset voltage: 10mV; (2)Ultra low drift: ±0.1mV/℃; (3)High open-loop gain: 134dB; (4)High common-mode rejection: 140dB; (5)High power supply rejection: 130dB; (6)Low bias current: 1nA max; (7)Wide supply range: ±2V to ±18V; (8)Low quiescent current: 800mA/amp; (9)Single, dual, and quad versions replaces OP-07, OP-77, OP-177.
