IR3088MTR

IR3088MTR, Phase IC, 27V, 50mA, 50 ns, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	0.50 / Piece

PartNumber:: IR3088MTR

Brand:: International Rectifier - IR | Pack: | D/C: 06+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-24

From Other Seller

Part Number:IR3088MTR
US $0.50 - 0.50
Quantity:

piece

Product Summary

The IR3088MTR Phase IC combined with an IR XPhase Control IC provides a full featured and flexible way to implement power solutions for the latest high performance CPUs and ASICs. The IR3088MTR provides overall system control and interfaces with any number of Phase ICs which each drive and monitor a single phase of a multiphase converter. The IR3088MTR architecture results in a power supply that is smaller, less expensive, and easier to design while providing higher efficiency than conventional approaches.

Parametrics

IR3088MTR absolute maximum ratings: (1)VMAX: 27V; (2)ISOURCE: 50mA; (3)Operating Junction Temperature: 150°C; (4)Storage Temperature Range: -65 to 150°C; (5)GATEH Rise Time VCCH = 12V, Measure 2V to 9V transition time: 22 to 50 ns; (6)Disable Pull-Down Current Force GATH or GATEL = 2V with BIASIN = 0V: 15 to 40 μA.

Features

IR3088MTR features: (1)2.5A Average Gate Drive Current; (2)Loss-Less Inductor Current Sense; (3)Internal Inductor DCR Temperature Compensation; (4)Programmable Phase Delay; (5)Programmable Feed-Forward Voltage Mode PWM Ramp; (6)Sub 100ns Minimum Pulse Width supports 1MHz per-phase operation; (7)Current Sense Amplifier drives a single wire Average Current Share Bus; (8)Current Share Amplifier reduces PWM Ramp slope to ensure sharing between phases; (9)Phase Fault Detection; (10)Programmable Phase Over-Temperature Detection; (11)Small thermally enhanced 20L MLPQ package.
