IR21084

IR21084, MOSFET and IGBT driver, 625V, 1.0W, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	1.50 / Piece

PartNumber:: IR21084

Brand:: International Rectifier - IR | Pack: DIP | D/C: 06+

Availability:: Supply Ability: 4/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sukey's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-24

From Other Seller

Part Number:IR21084
US $1.50 - 1.50
IR21084s,SOP14

US $0.31 - 0.35 / Piece
(0) Remove
IR21084S

US $0.45 - 0.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IR21084 is a high voltage, high speed power MOSFET and IGBT driver with independent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. The logic input of the IR21084 is compatible with standard CMOS or LSTTL output, down to 3.3V logic. The IR21084 features a high pulse current buffer stage designed for minimum driver cross-conduction.

Parametrics

IR21084 absolute maximum ratings: (1)VB High side floating absolute voltage: -0.3 to 625V; (2)dVS/dt Allowable offset supply voltage transient: 50 V/ns; (3)PD Package power dissipation @ TA ≤ +25°C (8 lead PDIP): 1.0W, (8 lead SOIC): 0.625W; (4)TJ Junction temperature: 150°C; (5)TS Storage temperature: -50 to 150°C; (6)TL Lead temperature (soldering, 10 seconds): 300°C.

Features

IR21084 features: (1)Gate drive supply range from 10 to 20V; (2)Undervoltage lockout for both channels; (3)3.3V, 5V and 15V input logic compatible; (4)Cross-conduction prevention logic; (5)Matched propagation delay for both channels; (6)High side output in phase with HIN input; (7)Low side output out of phase with LIN input; (8)Logic and power ground +/- 5V offset.; (9)Internal 540ns dead-time, and programmable up to 5us with one external RDT resistor; (10)Lower di/dt gate driver for better noise immunity; (11)Available in Lead-Free.
